090003077 ORIENTOR PAN ZINC PLATED

Often referred to as the "O-Pan" or "Turn Pan," this adjustable pan accepts pins from the elevator and positions them butt-first onto the distributor belt. A direct replacement for 070 006 144. The back edge of the pan should be as close as possible to the elevator wheel, but not touch it unless pushed outside of the 7 or 10 positions. The front flanges will spread apart over time. These need to be parallel with and flush against the support guides.
